Color Touch Panel Adds Convenience to Business Communication.
- 12 SIP accounts
- 4.3 - inch color TFT LCD with touch panel
- 24 flexible function keys
- HD Voice (G.722)
- Built-in Bluetooth®
- Up to 2,500 phonebook
- 3-way conference call support
- Compatible with Broadsoft UC one
- 2 x 10/100/1000M ports, PoE
- Low standby power consumption
- XML Application Interface
- Changeable angle stand
- Wall mounting
| Display | |
|---|---|
| LCD Display | 4.3 - inch color TFT LCD with touch panel |
| LCD Backlight | Active: 8 levels, Inactive: Low / Off |
| Install Options | |
| Desk Mount Tilt | Yes – 2 positions |
| Wall Mount | - (Included) |
| Power Adaptor | KX-A424 or KX-A422 (Optional) |
| Audio Features | |
| Handset, Speaker, Headset Volume | 8 levels (includes echo cancellation and distortion prevention) |
| Ringtones | 27 |
| Ringer Volume | 8 levels + Off |
| Headset Port | RJ9 jack |
| Electronic Hook Switch Control Port | 3.5 mm |
| Built-in Bluetooth® | Bluetooth V2.1 (Class1 / HFP) |
| Audio Codec | G.711a-law / G.711µ-law / G.722 (wideband) / G.729a |
| HD Voice | Yes |
| Speaker Phone | Speaker Phone(Full Duplex / Wideband) |
| Keys | |
| Flexible function keys | 24 (Touch Panel on LCD) |
| Software Features | |
| Phone Book (Local) | 2,500 (500 items x 5 numbers) |
| LDAP Remote Phonebook | Yes |
| XML Remote Phonebook | Yes |
| Call Log Entries | 30 incoming calls + 30 outgoing call |
| Conferencing | 3 parties (within terminal – multi-party dependent on server) |
| XML Application | Yes |
| Music on Hold | Supplied by Host Service (PBX / SIP Server) |
| IP Features | |
| SIP Accounts | 12 |
| SIP Compatibility | RFC 3261 Standard SIP Server, Asterisk, Broadsoft, Panasonic IP PBX |
| IP Version | IPv6 / IPv4 |
| DHCP Client | Yes |
| DNS | Yes |
| HTTP | Yes |
| HTTPS | Yes |
| SNTP Client | Yes |
| VLAN (802.1q) | Yes |
| QoS (DiffServ) | Yes |
| Configuration | |
| Plug & Play Configuration | Server based configuration, TR-069 |
| Manual Configuration | Internal web Configurator, Local (LCD based) network configuration |
| Interface | |
| Ethernet Ports | 2 |
| Ethernet Interface | 10/100/1000 Mbps |
| PoE (Power over Ethernet) | Yes |
| Others | |
| Power Consumption |
PoE |
| Operating Environment | 0 °C - 40 °C (32 °F - 104 °F) |
|
Dimensions (Width × Depth × Height; excluding the handset, stand attached) |
High position: 195 mm × 190 mm × 209 mm Low position: 195 mm × 184 mm × 188 mm |
|
Weight (with handset,handset cord and stand) |
850 g |
- The Bluetooth word mark is trademark or registered trademark owned by Bluetooth SIG, Inc. and any use of such mark by Panasonic Corporation is under license.
